Solid Carbide Spiral Flute Reamer .3548 Diameter ASM+ Coated $137.70
Solid Carbide Spiral Flute Reamer .3548 Diameter ASM+ Coated
Click to enlarge

Solid Carbide Spiral Flute Reamer .3548 Diameter ASM+ Coated
Click to enlarge 		Solid Carbide Spiral Flute Reamer .3548 Diameter ASM+ Coated
Click to enlarge
Solid Carbide Spiral Flute Reamer .3548 Diameter ASM+ Coated
Click to enlarge 		Solid Carbide Spiral Flute Reamer .3548 Diameter ASM+ Coated
Click to enlarge
Item No. 1378-.3548-3
Price: $137.70
Shipping: In Stock - Ships Same Day *
Quantity:

* Same Day Shipping is only available on orders placed Monday - Friday before 4 P.M. Central Time.
Available Downloads for 1378-.3548-3
PDF file
Product Info

View complete catalog page

  • Reamers are ideal for tight tolerance applications
  • Left hand spiral is ideal for better roundness and reaming holes with intersecting side holes or other features
  • Excellent for reaming Alum, brass, all steels, Stainless, Inconel, and Bronze
  • 45° chamfer lead
  • Solid Carbide - Right Hand Cut -Left hand 10 deg spiral
Product Specifications
Coating:  ASM+
Coolant Thru:  No
Cutting Diameter:  .3548 (9.01mm)
Cutting Diameter Tolerance:  -.0000/+.00012
End Style:  45 deg chamfer lead
Flute Length:  2.0 (50.8mm)
Helix Angle:  left spiral / right hand cut
Material:  Solid Carbide
Number of Flutes:  6 flute 10deg spiral
Reamer l2 length:  5.0 (127mm)
Shank Size:  .3937(10mm)
Total Length:  7.0 (177.8mm)
